How To Set Up Google Ads Remarketing Using Google Tag Manager

Last Modified on October 20, 2023

If your Google Ads implementation doesn’t include remarketing, then you’re missing out on some of your best leads!

This guide will show you how to set up a remarketing campaign in Google Ads with the help of Google Tag Manager so that you can turn leads into conversions.

GTM For Beginners

Sign up to the FREE GTM for Beginners Course...

🚨 Note: Learn how to optimize Google Ads Campaign using the top five strategies.

In this guide, we’ll cover how to:

Let’s get started!

Set Up an Audience Source

In your Google Ads account, go to Tools & Settings → Audience manager.

Audience manager in Tools & Settings menu

If this is your first time using Google Ads, you’ll be greeted with this screen.

Go ahead and click on Set Up an Audience Source. (If you’ve set up other audiences before, click on Audience sources in your sidebar.)

Setting up Audience Source

There are a variety of sources that you can link to your Google Ads account in order to create audiences. For this tutorial, we’re going to use the Google Ads tag.

Click Set Up Tag to create a data source for your audience.

Set up an Audience sources using Google Ads tag

There are two different remarketing options to choose from: one that targets all website visitors with general ads, and one that targets visitors who take specific actions on your website with personalized ad

Personalized ads are great when you have the data and resources to back them up, but let’s start simple.

Select the first option, Only collect general website visit data to show ads to your website visitors. This is the very general and basic remarketing setup that is easier to implement.

Selecting Only collect general website visit to show ads to your website visitor

You also have the option to restrict data processing in Google Ads in order to comply with data privacy laws.

If your audience includes users in the US, this will be important because of the California Consumer Privacy Act.

In order to comply with the CCPA, you should go ahead and check the box to Exclude California users from remarketing lists.

Basically, if there’s any chance that a visitor to your website might be in California, I highly recommend that you tick this box.

Checking the box which indicates excluding California users from remarketing lists

With step one completed, go ahead and click Save and Continue

Adding a Google Ads Remarketing Tag to GTM

Step two is to install the tag on our website. There are a few ways to do this, but if you already have Google Tag Manager installed, then the easiest option is to Use Google Tag Manager.

Selecting the Use Google Tag Manager in setting up tag in the website

All we need now in order to make our GTM tag work is this handy Conversion ID. Copy this for later.

Copy the Conversion ID to set up the tag in Google Tag Manager

Head on over to your Google Tag Manager account to set this up. Under the Tags view, click the New button to create a new tag.

Creating New tag by using the Tags Section

Click on the Tag Configuration field to choose a tag type. Select the Google Ads Remarketing tag type.

Choose tag type Google Ads Remarketing

Next, Google Tag Manager will need to know your Google Ads Conversion ID. You could just paste your Conversion ID into this field, but I wouldn’t recommend it.

The best practice is to set up your Conversion ID as a variable.

Since this string never changes, saving it as a constant in the form of a variable will help you seamlessly reuse your Conversion ID for other tags. You won’t have to dig it up on your Google Ads account again or risk copying the ID incorrectly.

To create a new variable, click on the variable icon next to the Conversion ID field.

Setting up the Conversion ID as variable

This will give you a list of existing variables to choose from. We don’t want to use any of these, though, so click on the plus sign ( + ) in the top right corner to create a new one.

To be in Variable Configuration, head over to the top right and press the blue (+)  button

Next, we’ll configure this variable to always be populated with our Google Ads Conversion ID.

Click anywhere in the Variable Configuration field and scroll down to select the variable type Constant

Choose Variable type Constant which means the value is set up to the string that you provide

For the Value, paste your Conversion ID. Give your variable an informative name, then click Save.

The process of adding value which is the copied Conversion ID, renaming the variable configuration to Google Ads Conversion ID then save

This will populate the Conversion ID field of your remarketing tag with the variable you just made. We’re almost done!

The renamed Google Ads Conversion ID is now showing in the Tag Configuration

The next step is to assign a trigger for this tag. Click anywhere in the Triggering field and select the All Pages trigger.

Choose a trigger All Pages to make the tag Google Ads Conversion ID fire

And that’s the full configuration for this tag. Give it a name and click Save

Saving the Google Ads Remarketing Tag Configuration set up

🚨 Note: If you want to maximize the return on your investment in ads check out our handy guide on Google Ads bidding strategies.

Create Audience Lists in Google Ads

Now that everything is set up on Google Tag Manager, go back to Google Ads and head over to your Audience lists.

Create Audience Lists in Google Ads

To create a new audience list, click on the blue plus ( + ) button.

 Create  Google Ads Audience lists  by  clicking the blue(+) button.

Since we’ve set up our tag with an “All Pages” trigger on our website, click on the Website visitors option to start building your audience list.

Selecting Website visitors for Google Ads Audience lists

Give this an audience name such as All Visitors. I recommend leaving the default settings: set members as Visitors of pages, and set the visited page to Match any rule group where the rule is Page URL contains [your domain].

Process of setting up Google Ads Audience lists by selecting  Website visitors

You can start this as an empty list, but if you have a website already up and running, I might recommend selecting the option Pre-fill with people who matched the rules within the past 30 days

Pre-fill list with people who matched the rules within the past 30 days

Next, you can determine the membership duration for this audience. This determines how long someone stays on this audience list after matching the rules. You can set a maximum of 540 days (I like to set mine to 90 days).

Enter the number of days that someone will stay on your remarketing list after interacting with your business

Finally, don’t forget to give your audience a descriptive name so that you know who is on this list.

Changing Audience name  All Visitors  to All Visitors - 90 Days

Then, just hit Create Audience to finish.

After setting up the information for your Audience Lists in Google Ads click Create Audience

🚨 Note: Your audience list will take about 24-48 hours to populate.

Types of Remarketing Lists

Remarketing is a powerful tool in the digital marketer’s arsenal, allowing businesses to reconnect with users who have previously interacted with their website or app. Depending on your goals and the nature of your audience’s interaction, you can leverage different types of remarketing lists:

  1. Standard Remarketing: This targets users who have previously visited your website. It’s a broad approach, ideal for general brand recall and awareness.
  2. Dynamic Remarketing: A more personalized approach, dynamic remarketing displays ads to past visitors based on the specific products, services, or content they viewed on your site. This often involves showing users the exact products they viewed or related items.
  3. Remarketing Lists for Search Ads (RLSA): With RLSA, you can customize your search ads for users who have previously visited your website and are now conducting related queries on search engines like Google.
  4. Video Remarketing: This targets users who have interacted with your videos or YouTube channel. It’s especially useful for businesses investing heavily in video content.
  5. Customer List Remarketing: If you have a list of email addresses from your customers, you can upload this to platforms like Google Ads to target these users with specific campaigns.


Why should I set up remarketing in Google Ads?

Setting up remarketing in Google Ads is beneficial because it allows you to reach out to people who have already shown an interest in your business. By displaying personalized ads to these individuals, you can reinforce your brand message, stay top-of-mind, and increase the likelihood of conversion.

How long does it take for the audience list to populate in Google Ads?

After creating an audience list in Google Ads, it typically takes about 24-48 hours for the list to populate. During this time, Google Ads collects data on users who match the defined rules for the audience. Once the list is populated, you can start using it to target your ads to specific audience segments.

Can I customize the membership duration of my audience list?

Yes, you can customize the membership duration for your audience list in Google Ads. The membership duration determines how long someone stays on the list after matching the defined rules. Google Ads allows you to set a maximum membership duration of 540 days. It is recommended to choose a duration that aligns with your marketing goals and the average conversion cycle of your business.


Now that your remarketing is configured with the help of both Google Ads and Google Tag Manager, you can start reaping the benefits of remarketing campaigns!

Although there is definitely an art to crafting the most effective audience lists and the sharpest remarketing campaigns, this technical guide will get you started. All that’s left is for you to try it yourself as a digital marketer.

If you want to analyze your users’ activity on your ad campaigns check out our guide on how to set up WooCommerce Google Ads conversion tracking.

What are some of your favorite remarketing tips? Have any questions about setting up your own remarketing campaign? Leave us a comment!
